Precision gear design and professional gear processing create low backlash operation,high efficiency,smooth running low noise and long life of the planetary gear with IP65 protection on most models.
*Multiple design configurations and performance leavels
*Adapters for all seavo moters
*Drop-ins for most industry standards
*Hardened and ground gearing
*One-piece planet carrier/output shaft on most models
*Planets with full needle bearing support
*IP65 protection on most models
PH Series
(Exactitude Helical Series Nickel-Plating)
|
PHL
(Nickel-Plating)
|
PHR
(Nickel-Plating)
|
PHF
(Nickel-Plating)
|
PG Series
(Precision Helical & Spur Series Nickel-Plating/
Baking Varnish)
|
PGH
(Helical,
Nickel-Plating)
|
PGRH
(Helical,
Nickel-Plating) |
PGF
(Helical,
Nickel-Plating) |
PGL
(Nickel-Plating)
|
PGR
(Nickel-Plating)
|
PGLH
(Helical,
Nickel-Plating) |
|
PGL
(Baking-Vamish)
|
PGC
(Baking-Vamish)
|
PGE
(Baking-Vamish)
|
|
PE Series
(Standard Spur Series Baking-Vamish)
|
PEL
(Baking-Vamish)
|
PEC
(Baking-Vamish)
|
PEE
(Baking-Vamish)
|
PC Series
(Primary Spur Series
Baking-Vamish)
|
PCL
(Baking-Vamish)
|
Sesame planetary speed reducer coding system
P
|
Planetary
|
|
G
|
(Grade)
|
H: Exactitude Helical Series
|
G: Precision Series
|
||
E: Eifficient Series
|
||
C: Primary Series
|
||
U: Heavy Duty Series
|
||
B: Muti-Ratio Series
|
||
T: Muti-Shafted Series
|
||
P: Light Load Series
|
||
L
|
(Connection)
|
L: Square Housing with Flange
|
C: Round Housing without Flange
|
||
E: Round Housing with Flange
|
||
R: Right Angle
|
||
F: Plate Type
|
||
H: Square Flange Helical Gear ( Square Flange Helical Gear for G Grade(Precision Series) only)
|
||
60
|
(Size)
|
42:__42 60:__60 90:__90 115:__115
142:___142 180:____180 220:____220
|
30
|
(Speed Reduction Ratio)
|
Single Stage:3,4,5,6,7,8,9,10
Double Stage: 12,15,20,25,30,35,40,45,50,60,70,80,90,100
Muti-Stage: 125~1000
|
P1
|
(Backlash)
|
P0: Micro Backlash
P1: Precision Backlash
P2: Standard Backlash
|
Y
|
(Customer Specification)
|
|
Motor
|
(Motor Model)
|
Please send inquiry to us for discussing the customized products.
Sesame Planetary Gear heads are produced under strictly exclusive pairing process to ensure accuracy and lifespan.
Motor
Shaft
Dia.
|
Flange
Dia.
|
Motor
Shaft
Length
|
Flange
Height
|
P.C.D
of
Bore
|
Bore
Dia.
|
Motor
Flange
Square
|
Actual
Length
of
Motor
Shaft
|
Backlash
|
ØA
(h6)
|
ØB
(h7)
|
C
|
D
|
ØE
|
ØF
|
__H
|
L
|
P1/P1/
P2
|
